Magnetic Drive Model | Magnetic torque at room temperature N·m | Working pressure MPa | Use temperature ℃ | Kettle volume | Motor reducer specifications |
Motor power KW/speed rpm |
CLJ-40 | 40 | -0.1～0.6 | -20～60 | 50 | 0.75/160*,0.55/130,0.37/85,0.25/63 |
CLJ-63 | 63 | 100 | 1.1/160*,1.1/130*,0.75/100*,0.75/85* |
CLJ-80 | 80 | 200 | 1.1/160,1.1/130*,0.75/85* |
CLJ-100 | 100 | 300 | 1.5/160,1.5/130*,1.1/100*,1.1/85* |
CLJ-125 | 125 | 400 | 2.2/130*,1.5/100*,1.5/85*,1.1/85 |
CLJ-160 | 160 | 500 | 3/160*,2.2/130*,2.2/100*,1.5/85,1.1/63* |
CLJ-200 | 200 | 600 | 4/200,3/160,3/130*,2.2/100*,1.5/85,1.1/63 |
CLJ-250 | 250 | 700 | 5.5/200*,5.5/160*,4/130,3/100*,2.2/85,1.5/63 |
CLJ-315 | 315 | 800 | 7.5/200*,5.5/160*,4/110*,3/85*,2.2/63* |
CLJ-400 | 400 | 1000 | 7.5/200,7.5/160*,5.5/130*,5.5/100*,4/85*,3/63* |
CLJ-500 | 500 | 1500 | 15/250*,11/200*,7.5/130*,5.5/100*,4/85,3/63 |
CLJ-630 | 630 | 2000 | 15/200*,11/160*,7.5/110*,5.5/85,4/63 |
CLJ-800 | 800 | 2500 | 18.5/200*,15/160*,11/130*,7.5/100,7.5/85*,5.5/63* |
CLJ-1000 | 1000 | 3000 | 22/200*,18.5/160*,15/130*,11/100*,7.5/85,7.5/63* |
CLJ-1250 | 1250 | 4000 | 22/160*,18.5/130*,15/110*,11/85,7.5/63 |
CLJ-1400 | 1400 | 5000 | 22/130*,18.5/110*,15/100*,11/63*,7.5/58* |
CLJ-1600 | 1600 | 6000 | 22/130*,18.5/110*,15/100,15/85*,11/69,11/63* |
CLJ-1800 | 1800 | 8000 | 30/160,22/125,22/110*,15/85,11/63,11/58* |
CLJ-2000 | 2000 | 10000 | 30/150,30/130*,22/110,22/100*,15/69*,15/65* |
